Description
| Model No. | AST-HB23-150WS1BT2C1-BH35/40/50WD |
| Beam Angle | 90° |
| Brightness | 12000/15000/22500Lm |
| Color Temperature |
3500K, 4000K, 5000K Adjustable |
| Rendering Index |
>80 |
| Dimension | 10.83"x6.88" (275.08 x 174.75mm) |
| AC120-347V | |
| Power | 80W, 100W, 150W Adjustable |
| Power Factor | >0.9 |
| Special Features | Remote Control, Sensor |
| IP Rating | IP65 |
| Hardware included | 6" power cable and 6" dimming cable included in all luminaires |
| Accessories (Sold Separately) | 3-pin UFO DC sensor: UFO DC sensor HB18B HB03R: Remote Control for Sensor for HB18B 1-pin UFO DC sensor: UFO DC sensor HB23B RC100 / UFO / HB23: Remote Control for Sensor for HB23B Safety Rope: 4ft / Steel 100W/150W UFO Reflector(HB18B): 90 Degree Beam angel, Acrylic 200W/240W UFO Reflector(HB18B): 90 Degree Beam angel, Acrylic PC Cover Reflector: PC Cover 90° 90 degree For HB18B 100 150W UFO and UHB23 150W 240W |
| Certification |  |
Features
- Adjustable power settings of 80W, 100W, and 150W, offering flexibility for diverse lighting needs.
- Delivers brightness levels of 12,000Lm, 15,000Lm, and 22,500Lm for optimal illumination.
- Adjustable color temperature settings (3500K, 4000K, and 5000K) for customizable lighting environments.
- A focused 90° beam angle ensures efficient light distribution.
- Operates on an input voltage range of AC120-347V, making it compatible with various electrical systems.
- High energy efficiency with a power factor of >0.9.
- IP65-rated for water and dust resistance, suitable for both indoor and outdoor applications.
- Remote control and sensor capabilities enhance convenience and automation.
- Includes 6" power and dimming cables with all luminaires for easy installation.
- Versatile accessories for additional customization, including:
- 3-pin and 1-pin UFO DC sensors for automation and energy savings.
- Remote controls (HB03R and RC100) for advanced sensor management.
- Safety rope (4ft, steel) for secure mounting.
- Reflectors with a 90° beam angle in acrylic and PC cover options, compatible with HB18B and UHB23 models.
