Description
| Model No | CBAC-84-30135-120V-40 (Paragon) VBDMDL-553839-16W-9XXK-120V (Veroboard) |
| COB Holder Model No | GPH48135AC |
|
LED Type |
COB LED |
| Wattage | 16W |
| Voltage | 120V AC |
| Brightness | 1280 Lumens |
| Available Color Temperature | (Paragon) 4000K (Natural White) (Veroboard) 2700K (Soft White) 3000K (Warm White) 4000K (Natural White) |
| Dimmable | Yes |
| Rendering Index | CRI>80 (Paragon) CRI>95 (Veroboard) |
| IP Rating | IP20 (Indoor rated) |
| COB Holder Dimensions |
(Paragon) (Veroboard) |
| COB Module Outer Diameter | ∅27mm (1.06 in) (Paragon) ∅10mm (0.39in) (Veroboard) |
| Operating Temperature | -60 ~ +105℃ |
| Storage Temperature | -60 ~ +105℃ |
| Assembly process Temperature | <300℃ |
| Solder joint point | <105℃ |
| Dielectric Breakdown Voltage of Thermal Pad | >4KV |
| Included Content | COB Module, COB Holder with Thermal Pad |
| Weight | 0.04 kg |
| Certifications |  |
Features:
- 16W wattage and 120V AC voltage rating
- COB LED technology provides 1280 lumens of brightness
- Includes silicone grease thermal pad for heat dissipation and increased lifespan
- Operating temperature range is -60 ~ +105℃ and assembly process temperature should be below 300℃
- Dielectric breakdown voltage of thermal pad of >4KV and certified by UL
- Aluminum heat sink required to prevent overheating and serious luminous decay
- COB LEDs are brighter, consume less power, and have a higher quality beam output compared to older LED technologies
- Used in almost every kind of luminaire and it is important to ground light fixtures during design
