CBHT-042-30135-120V-40-G03 COB Paragon LED Module with GHH36135AC LED Holder, 120V 6W 4000K

SKU: 666561428297

Inquiry

Description

Model No CBHT-042-30135-120V-40-G03
COB Holder Model No GHH36135AC
LED Type
COB LED
No LED chips 42
Wattage 6W
Voltage 120 VAC
Power Factor PF>0.98
Luminous Intensity 560 lumens
Color Temperature 4000K (Natural White)
Dimmable Yes
Rendering Index CRI>90
IP Rating IP20 (Indoor rated)
COB Holder Dimensions ∅36mm (1.4 in) x H11.60mm (0.45 in)
COB Module Outer Diameter ∅27 mm (1.06 in)
Operating Temperature -40 ~ +105℃
Storage Temperature -40 ~ +105℃
Assembly process Temperature <300℃
Solder joint point <105℃
Dielectric Breakdown Voltage of Thermal Pad >4KV
Included Content COB Module, COB LED Array Holder, Thermal Pad
Certifications


Features:

  • Low power consumption and high energy efficiency.
  • Suitable for damp locations.
  • Requires an aluminum heat sink to prevent overheating, which can cause serious luminous decay.
  • COB LEDs are brighter, consume less power, and provide higher quality beam output compared to older LED technologies.
  • It is important to ground light fixtures while designing lamps.
  • This product includes a polycarbonate diffuser that can be easily attached or detached. The diffuser not only protects the module but also helps reduce glare and refract light in a wider beam.
  • COB LEDs are commonly used in almost every kind of luminaire.
  • The COB holder allows the module to be mechanically secured, electrically connected, and pressed to a heat sink.
  • The silicone grease thermal pad provides a heat sink and aids in better heat dissipation, thereby increasing the lifespan of the module.
