1.5 inch Round Disc LED Module P01-600-930-120-S1-18S300, 120V 7W 3000K(Warm White)

SKU: 666561432539



Product LED Module
Model No P01-600-930-120-S1-18S300
No of LEDs 7
Wattage 7W
Voltage 120V AC
Luminous Flux 600 lumens
Color Temperature 3000K (Warm White)
Rendering Index CRI>90
Power Source AC
Dimmable Yes
Base Material Aluminum (Metallic Base)
Package Components  LED Module
Thermal Silicon Pad
6inch Black and White power feed
Outer Diameter
∅38mm (1.5 in)
Diameter of the screw hole ∅2.5 mm (0.1 in)
Distance between holes 27.5mm (1.08 in)
Height 8.3mm (0.32 in)


  • 7 high-quality LEDs that produce 600 lumens of warm white light with a color temperature of 3000K
  • Low power consumption of 7W and high energy efficiency that saves on energy costs
  • Operates on a voltage of 120V AC and is dimmable for greater flexibility in lighting control
  • Constructed with an aluminum (metallic base) material, with an outer diameter of ∅38mm (1.5 in) for easy installation
  • Includes a thermal silicon pad and a 6-inch black and white power feed for added convenience
  • etl certified, ensuring that it meets high safety and quality standards
  • High rendering index of CRI>90, making colors appear more vibrant and true-to-life
  • Ideal for a wide range of general lighting applications due to its superior quality, energy efficiency, and flexibility
  • A premier quality light engine. It produces up to 600 lumens of exceptional light.
  • Low power consumption, high energy efficiency.
  • It is a good DIY product for the replacement of a ceiling light/ Bulb source.
  • Apply Thermal Silicon Pad evenly on the bottom of the light source and the contact surface of the heat sink when installation.
