CBAC-042-36185-120V-2700K COB Paragon LED Module with H48185 LED Holder, 120V 11W 2700K(Soft White)

SKU: 666561433475



Model No CBAC-042-36185-120V-2700K
COB Holder Model No H48185
LED Type
Wattage 11W
Voltage 120V AC
Power Factor PF>0.98
Color Temperature 2700K (Soft White)
Brightness 880 Lumens
Dimmable Yes
Rendering Index CRI>90
IP Rating IP20 (Indoor rated)
COB Holder Dimensions ∅42.3mm (1.6 in) x H5.88mm (0.23 in)
Operating Temperature -40 ~ +105℃
Storage Temperature -40 ~ +105℃
Assembly process Temperature <300℃
Solder joint point <105℃
Dielectric Breakdown Voltage of Thermal Pad >4KV
Included Content COB Module, PC lampshade (Diffuser), COB LED Array Holder, Thermal Pad


  • COB LED module designed for indoor use with a power consumption of 11W and a voltage rating of 120V AC
  • Color temperature of 2700K, producing a soft white light
  • Dimmable module with a high color rendering index of over 90, ensuring accurate color display
  • Comes with a H48185 COB LED holder that allows for easy mechanical and electrical connections and secure attachment to a heat sink
  • COB holder dimensions: ∅42.3mm (1.6 in) x H5.88mm (0.23 in)
  • Recommended to use an aluminum heat sink and silicone grease thermal pad to prevent overheating and ensure longevity of the module
  • Includes a polycarbonate diffuser that can be easily attached or detached to protect the module, reduce glare, and refract light in a wider beam
  • Certified by UL and suitable for use in damp locations
  • Important to ground light fixtures when designing lamps to ensure safe operation
  • Operating temperature range: -40 ~ +105℃, storage temperature range: -40 ~ +105℃
  • Assembly process temperature should not exceed 300℃ and the solder joint point temperature should not exceed 105℃
  • Dielectric breakdown voltage of the thermal pad is greater than 4KV
