CDAC-136-05028-347-2700K COB Paragon LED Module with HT5828 LED Holder, 347V 30W 2700K

SKU: 666561430696

Description

Model No CDAC-136-05028-347-2700K
COB Holder Model No HT5828
LED Type
COB LED
No LED chips 136
Wattage 30W
Voltage 347V AC
Power Factor PF>0.85
Luminous Intensity 3150 Lumens
Color Temperature 2700K (Soft White)
Dimmable Yes
Rendering Index CRI>80
IP Rating IP20 (Indoor rated)
COB Holder Dimensions ∅50mm (1.9in) x H7.8mm (0.3 in)
COB Module Outer Diameter ∅28mm (1.1 in)
Operating Temperature -40 ~ +105℃
Storage Temperature -40 ~ +105℃
Included Content COB Module, COB LED Array Holder, Thermal Pad
Certifications



Features:

  • Low power consumption and high energy efficiency.
  • Suitable for damp locations.
  • Requires an aluminum heat sink to prevent overheating, which can cause serious luminous decay.
  • COB LEDs are brighter, consume less power, and provide a higher quality beam output compared to older LED technologies.
  • It is important to ground light fixtures while designing lamps.
  • COB LEDs are generally used in almost every kind of luminaire.
  • The COB holder, equipped with a glass diffuser, allows the module to be mechanically secured, electrically connected, and pressed to a heat sink.
  • The silicone grease thermal pad acts as a heat sink and aids in better heat dissipation, thereby increasing the module's lifespan.
