CDAC-136-05028-347-3000K COB Paragon LED Module with HT5828 LED Holder, 347V 30W 3000K

SKU: 666561430702


Model No CDAC-136-05028-347-3000K
COB Holder Model No HT5828
LED Type
No LED chips 136
Wattage 30W
Voltage 347V AC
Power Factor PF>0.85
Luminous Intensity 3150 Lumens
Color Temperature 3000K (Warm White)
Dimmable Yes
Rendering Index CRI>80
IP Rating IP20 (Indoor rated)
COB Holder Dimensions ∅50mm (1.9in) x H7.8mm (0.3 in)
COB Module Outer Diameter ∅28mm (1.1 in)
Operating Temperature -40 ~ +105℃
Storage Temperature -40 ~ +105℃
Included Content COB Module, COB LED Array Holder, Thermal Pad



  • Low power consumption and high energy efficiency.
  • Suitable for damp locations.
  • Requires an aluminum heat sink to prevent overheating or serious luminous decay.
  • COB LEDs are brighter, consume less power, and provide a higher quality beam output compared to older LED technologies.
  • It is important to ground light fixtures while designing lamps.
  • COB LEDs are commonly used in various types of luminaires.
  • This COB holder with the glass diffuser allows for secure mechanical attachment, electrical connection, and pressing to a heat sink.
  • The silicone grease thermal pad serves as a heat sink and facilitates better heat dissipation, thereby increasing the module's lifespan.
