CDAC-136-05028-347-5000K COB Paragon LED Module with HT5828 LED Holder, 347V 20W 5000K

SKU: 666561430689



Model No CDAC-136-05028-347-5000K
COB Holder Model No HT5828
LED Type
No LED chips 136
Wattage 20W
Voltage 347V AC
Power Factor PF>0.85
Luminous Intensity 2400 Lumens
Color Temperature 5000K (Daylight)
Dimmable Yes
Rendering Index CRI>80
IP Rating IP20 (Indoor rated)
COB Holder Dimensions ∅58mm (2.7in) x H8mm (0.3 in)
COB Module Outer Diameter ∅29mm (1.1 in)
Operating Temperature -40 ~ +105℃
Storage Temperature -40 ~ +105℃
Included Content COB Module, COB LED Array Holder, Thermal Pad



  • Low power consumption and high energy efficiency.
  • Suitable for damp locations.
  • Requires an aluminum heat sink to prevent overheating, which can cause serious luminous decay.
  • COB LEDs are brighter, consume less power, and provide a higher quality beam output compared to older LED technologies.
  • It is important to ground light fixtures during the design of lamps.
  • COB LEDs are commonly used in various types of luminaires.
  • This COB holder, equipped with a glass diffuser, allows for secure mechanical attachment, electrical connection, and pressing to a heat sink.
  • The silicone grease thermal pad serves as a heat sink and enhances heat dissipation, thereby increasing the module's lifespan.
