CDAC-136-05028-347-5000K COB Paragon LED Module with HT5828 LED Holder, 347V 30W 5000K

SKU: 666561430719



Model No CDAC-136-05028-347-5000K
COB Holder Model No HT5828
LED Type
No LED chips 136
Wattage 30W
Voltage 347V AC
Power Factor PF>0.85
Luminous Intensity 3300 Lumens
Color Temperature 5000K (Daylight)
Dimmable Yes
Rendering Index CRI>80
IP Rating IP20 (Indoor rated)
COB Holder Dimensions ∅58mm (2.7in) x H8mm (0.3 in)
COB Module Outer Diameter ∅29mm (1.1 in)
Operating Temperature -40 ~ +105℃
Storage Temperature -40 ~ +105℃
Included Content COB Module, COB LED Array Holder, Thermal Pad



  • The product features low power consumption and high energy efficiency.
  • It is suitable for damp locations.
  • To prevent overheating or serious luminous decay, it requires an aluminum heat sink.
  • COB LEDs are known for being brighter, consuming less power, and delivering a higher quality beam output compared to older LED technologies.
  • When designing lamps, please ensure that light fixtures are properly grounded.
  • COB LEDs are commonly used in a wide range of luminaires.
  • The COB holder with a glass diffuser allows for mechanical securing, electrical connection, and pressing to a heat sink.
  • The silicone grease thermal pad acts as a heat sink and facilitates better heat dissipation, thereby increasing the module's lifespan.
