CDAC-20-30135-120V-30 COB Paragon LED Module with H42135AC LED Holder, 120V 6W 3000K

SKU: 666561425852

Inquiry

Description

Model  CDAC-20-30135-120V-30
COB Holder Model No H42135AC
LED Type
COB LED
No LED chips 20
Wattage: 6W
Voltage: 120V AC
Luminous Intensity 420 lumens
Color Temperature 3000K (Warm White)
Dimmable Yes
Rendering Index CRI>90
IP Rating IP20 (Indoor rated)
COB Holder Dimensions ∅42.3mm (1.66 in) x H6mm (0.23 in)
COB Module Outer Diameter ∅27 mm (1.06 in)
Operating Temperature -60 ~ +105℃
Storage Temperature -60 ~ +105℃
Assembly process Temperature <300℃
Solder joint point <105℃
Dielectric Breakdown Voltage of Thermal Pad >4KV
Included Content COB Module, COB LED Holder, Thermal Pad
Certifications



Features:

  • Low power consumption and high energy efficiency.
  • Suitable for damp locations.
  • An aluminum heat sink is required to prevent overheating, as failure to do so may result in serious luminous decay.
  • COB LEDs are brighter, consume less power, and provide higher quality beam output compared to older LED technologies.
  • Ground light fixtures during the design process.
  • COB LEDs are commonly used in various types of luminaires.
  • The COB holder allows for mechanical securing, electrical connection, and pressing to a heat sink.
  • The silicone grease thermal pad serves as a heat sink and aids in better heat dissipation, thereby increasing the lifespan of the module.
